| MODEL
NO. |
NUMBER OF BALL ROWS |
MAIN
DIMENSIONS |
SQUA-RENESS |
ECCEN-TIRICITY(MAX.) |
BASIC LOAD
RATING |
| INSCRIBED CIRCLE |
OUTER DIAMETER |
LENGTH |
I |
FLANGE |
HOLE FOR ATTACHMENT |
c(kgf) |
Co(kgf) |
| dr |
TOLE-RANCE |
D |
TOLE-RANCE |
L |
TOLE-RANCE |
D1 |
W |
H |
A |
F |
d1 |
d2 |
h |
| LMTP6 |
4 |
6 |
-0
-0.009 |
12 |
-0
-0.013 |
19 |
±0.30 |
5 |
28 |
18 |
5 |
20 |
|
3.5 |
6 |
3.1 |
0.012 |
0.012 |
21 |
27 |
| LMTP8 |
4 |
8 |
15 |
24 |
5 |
32 |
21 |
5 |
24 |
|
3.5 |
6 |
3.1 |
27 |
41 |
| LMTP10 |
4 |
10 |
19 |
-0
-0.016 |
29 |
0
-0.20 |
6 |
40 |
25 |
6 |
29 |
|
4.5 |
7.5 |
4.1 |
38 |
56 |
| LMTP12 |
4 |
12 |
21 |
30 |
6 |
42 |
27 |
6 |
32 |
|
4.5 |
7.5 |
4.1 |
42 |
61 |
| LMTP13 |
4 |
13 |
23 |
32 |
6 |
43 |
29 |
6 |
33 |
|
4.5 |
7.5 |
4.1 |
52 |
79 |
| LMTP16 |
5 |
16 |
28 |
37 |
6 |
48 |
34 |
6 |
31 |
22 |
4.5 |
7.5 |
4.1 |
79 |
120 |
| LMTP20 |
5 |
20 |
-0
-0.01 |
32 |
-0
-0.019 |
42 |
8 |
54 |
38 |
8 |
36 |
24 |
5.5 |
9 |
5.1 |
0.015 |
0.015 |
88 |
140 |
| LMTP25 |
6 |
25 |
40 |
59 |
0
-0.30 |
8 |
62 |
46 |
8 |
40 |
32 |
5.5 |
9 |
5.1 |
100 |
160 |
| LMTP30 |
6 |
30 |
45 |
64 |
10 |
74 |
51 |
10 |
49 |
35 |
6.6 |
11 |
6.1 |
160 |
280 |
|
