| MODEL
NO. |
OUTER
DIAMETER |
DIAMETER
TOLERANCE |
LENGTH |
DEPTH OF
EFFECTIVE HARDENED LAYER |
WEIGHT(kg/m) |
| g6 |
h6 |
| S6 |
6 |
-0.004
-0.012 |
0
-0.008 |
100-2000 |
>0.8 |
0.22 |
| S8 |
8 |
-0.005
-0.014 |
0
-0.009 |
100-2000 |
0.40 |
| S10 |
10 |
-0.005
-0.014 |
0
-0.009 |
100-2000 |
>1.0 |
0.62 |
| S12 |
12 |
-0.006
-0.017 |
0
-0.011 |
100-3000 |
0.89 |
| S13 |
13 |
100-3500 |
1.04 |
| S16 |
16 |
100-4000 |
>1.5 |
1.58 |
| S20 |
20 |
-0.007
-0.020 |
0
-0.013 |
100-6000 |
2.47 |
| S25 |
25 |
3.85 |
| S30 |
30 |
>2.0 |
5.55 |
| S35 |
35 |
-0.009
-0.025 |
0
-0.016 |
7.55 |
| S40 |
40 |
>2.5 |
9.87 |
| S50 |
50 |
15.4 |
|
