| MODEL
NO. |
SHAFT DIAMETER |
MAIN
DIMENSIONS |
MOUNTING
DIMENSIONS |
WEIGHT
（Kg) |
| H |
E |
W |
L |
F |
G |
T |
N |
h1 |
B
|
C |
S1 |
S2 |
I |
K |
| KBB16AJ |
16 |
22 |
26.5 |
53 |
43 |
42 |
32 |
7 |
30 |
1.5 |
40 |
26 |
M6 |
5.3 |
13 |
6.5 |
0.19 |
| KBB20AJ |
20 |
25 |
30 |
60 |
54 |
50 |
39 |
7.5 |
34 |
2 |
45 |
32 |
M8 |
6.6 |
18 |
7.5 |
0.31 |
| KBB25AJ |
25 |
30 |
39 |
78 |
67 |
60 |
48 |
8.5 |
40 |
2 |
60 |
40 |
M10 |
8.4 |
22 |
9 |
0.86 |
| KBB30AJ |
30 |
35 |
43.5 |
87 |
79 |
70 |
57 |
9.5 |
48 |
2 |
68 |
45 |
M10 |
8.4 |
22 |
9.5 |
0.91 |
|
