| MODEL NO. |
Assembled Dimension |
Seat Dimension(mm) |
Track Dimension(mm) |
| H |
W |
W2 |
E |
L |
BXJ |
MQX& |
L1 |
Hole of oil |
T1 |
N |
W1 |
H1 |
F |
dXDXh |
| HLH15A |
24 |
47 |
16 |
4.6 |
66 |
38X30 |
M5X8 |
40 |
ø3 |
4.3 |
5 |
15 |
14 |
60 |
4.5X7.5X5.3 |
| HLH20A |
30 |
63 |
21.5 |
5 |
77.8 |
53X40 |
M6X9 |
48.8 |
M6X1 |
5 |
6.5 |
20 |
18 |
60 |
6X9.5X8.5 |
| HLH20AL |
92.4 |
63.4 |
| HLH25A |
36 |
70 |
23.5 |
7 |
88 |
57X45 |
M8X12 |
57 |
M6X1 |
5 |
6.5 |
23 |
22 |
60 |
7X11X9 |
| HLH25AL |
110.1 |
79.1 |
| HLH30A |
42 |
90 |
31 |
9 |
109 |
72X52 |
M10X12 |
72 |
M6X1 |
7 |
6.5 |
28 |
26 |
80 |
9X14X12 |
| HLH30AL |
131.3 |
94.3 |
| HLH35A |
48 |
100 |
33 |
9.5 |
119 |
82X62 |
M10X13 |
80 |
M6X1 |
8 |
6.5 |
34 |
29 |
80 |
9X14X12 |
| HLH35AL |
144.8 |
105.8 |
| HLH45A |
60 |
120 |
37.5 |
14 |
148.2 |
100X80 |
M12X15 |
105 |
M8X1 |
10 |
13 |
45 |
38 |
105 |
14X20X17 |
| HLH45AL |
173 |
129.8 |
| HLH55A |
70 |
140 |
43.5 |
15 |
170 |
116X95 |
M14X20 |
121 |
M8X1 |
11 |
13 |
53 |
44 |
105 |
16X23X20 |
| HLH55AL |
205.1 |
156.1 |
| MODEL NO. |
(mm) |
Basic Loas Rating |
(kgf*m) |
Weight |
| Lmax |
G |
C(kgf) |
Co(G) |
Mx |
My |
Mz |
Block(kgf) |
Track(kgf/M) |
| HLH15A |
4000 |
20 |
850 |
1650 |
10 |
8 |
8 |
0.19 |
1.4 |
| HLH20A |
4000 |
20 |
1450 |
2560 |
22 |
18 |
18 |
0.4 |
2.6 |
| HLH20AL |
1900 |
3330 |
28.6 |
23.4 |
23.4 |
0.52 |
| HLH25A |
4000 |
20 |
2140 |
4000 |
36 |
31 |
31 |
0.57 |
3.6 |
| HLH25AL |
2996 |
5600 |
50.4 |
43.4 |
43.4 |
0.72 |
| HLH30A |
4000 |
20 |
2980 |
5490 |
60 |
49 |
49 |
1.1 |
5.2 |
| HLH30AL |
3900 |
7190 |
78.5 |
65 |
65 |
1.4 |
| HLH35A |
4000 |
20 |
3960 |
7010 |
96 |
73 |
73 |
1.6 |
7.2 |
| HLH35AL |
5230 |
9270 |
125 |
95 |
95 |
2 |
| HLH45A |
4000 |
22.5 |
6740 |
12100 |
216 |
168 |
168 |
2.7 |
12.3 |
| HLH45AL |
8330 |
14950 |
267 |
210 |
210 |
3.6 |
| HLH55A |
4000 |
30 |
9940 |
17100 |
367 |
288 |
288 |
5 |
16.9 |
| HLH55AL |
12820 |
22060 |
473 |
375 |
375 |
6.4 |
|
