| MODEL NO. |
NUMBER OF BALL |
MAIN DIMENSIONS |
CLEARANCE |
BASIC LOAD
RATING |
| dr |
D |
L |
B |
D1 |
W |
E |
F |
G |
J |
H7/h6 |
DYNAMIC
c(kgf) |
STATIC
Co(kgf) |
| SSW8OP |
4 |
1/2 ˝
12.7 |
0.875 ˝
22.225 |
1.25 ˝
31.75 |
1.032˝
26.213 |
0.8209 ˝
20.85 |
0.0459 ˝
1.166 |
0.313˝
7.95 |
0.136˝
3.45 |
0.625˝
15.875 |
|
+0.011~+0.042 |
104 |
132 |
| SSW10OP |
4 |
5/8 ˝
15.875 |
1.125 ˝
28.575 |
1.5 ˝
38.1 |
1.112˝
28.245 |
1.059 ˝
26.899 |
0.0559 ˝
1.42 |
0.375˝
9.525 |
0.105˝
2.667 |
0.125˝
3.175 |
0.039
0.991 |
+0.011~+0.042 |
182 |
228 |
| SSW12OP |
4 |
3/4 ˝
19.05 |
1.25 ˝
31.75 |
1.625 ˝
41.275 |
1.272˝
32.309 |
1.176 ˝
29.87 |
0.0559 ˝
1.42 |
0.438˝
11.125 |
0.136˝
3.454 |
0.125˝
3.175 |
0.059
1.499 |
+0.012~+0.050 |
213 |
268 |
| SSW16OP |
5 |
1 ˝
25.4 |
1.5625 ˝
39.688 |
2.25 ˝
57.15 |
1.886˝
47.904 |
1.4687 ˝
37.305 |
0.0679 ˝
1.725 |
0.563˝
14.3 |
0.136˝
3.454 |
0.125˝
3.175 |
0.047
1.194 |
+0.012~+0.050 |
386 |
481 |
| SSW20OP |
5 |
1-1/4 ˝
31.75 |
2 ˝
50.8 |
2.625 ˝
66.675 |
2.011˝
51.079 |
1.8859 ˝
47.9 |
0.0679˝
1.725 |
0.625˝
15.875 |
0.201˝
5.105 |
0.1875˝
4.763 |
0.09
2.286 |
+0.012~+0.050 |
558 |
695 |
| SSW24OP |
6 |
1-1/2 ˝
38.1 |
2.375 ˝
60.325 |
3 ˝
76.2 |
2.422˝
61.519 |
2.2389 ˝
56.868 |
0.0859 ˝
2.182 |
0.75˝
19.05 |
0.201˝
5.105 |
0.1875˝
4.763 |
0.09
2.286 |
+0.013~+0.055 |
672 |
840 |
| SSW32OP |
6 |
2 ˝
50.8 |
3 ˝
76.2 |
4 ˝
101.6 |
3.206˝
81.432 |
2.8379 ˝
72.083 |
0.1029 ˝
2.614 |
1˝
25.4 |
0.265˝
6.731 |
0.3125˝
7.938 |
|
+0.013~+0.055 |
1102 |
1377 |
|
