| MODEL
NO. |
SHAFT
DIAMETER |
MAIN
DIMENSIONS |
MOUNTING
DIMENSIONS |
WEIGHT(kg) |
| h |
E |
W |
L |
F |
G |
T |
B |
C |
K |
S1 |
S2 |
l |
| SMA8L |
8 |
11 |
17 |
34 |
58 |
22 |
18 |
6 |
24 |
42 |
5 |
M4 |
3.4 |
8 |
0.1 |
| SMA10L |
10 |
13 |
20 |
40 |
68 |
26 |
21 |
8 |
28 |
46 |
6 |
M5 |
4.3 |
12 |
0.18 |
| SMA12L |
12 |
15 |
21 |
42 |
70 |
28 |
24 |
8 |
30.5 |
50 |
5.75 |
M5 |
4.3 |
12 |
0.20 |
| SMA13L |
13 |
15 |
22 |
44 |
75 |
30 |
24.5 |
8 |
33 |
50 |
5.5 |
M5 |
4.3 |
12 |
0.23 |
| SMA16L |
16 |
19 |
25 |
50 |
85 |
38.5 |
32.5 |
9 |
36 |
60 |
7 |
M5 |
4.3 |
12 |
0.39 |
| SMA20L |
20 |
21 |
27 |
54 |
96 |
41 |
35 |
11 |
40 |
70 |
7 |
M6 |
5.2 |
12 |
0.49 |
| SMA25L |
25 |
26 |
38 |
76 |
130 |
51.5 |
42 |
12 |
54 |
100 |
11 |
M8 |
7 |
18 |
1.165 |
| SMA30L |
30 |
30 |
39 |
78 |
140 |
59.5 |
49 |
15 |
58 |
110 |
10 |
M8 |
7 |
18 |
1.43 |
| SMA35L |
35 |
34 |
45 |
90 |
155 |
68 |
54 |
18 |
70 |
120 |
10 |
M8 |
7 |
18 |
2.13 |
| KBA40L |
40 |
40 |
51 |
102 |
175 |
78 |
62 |
20 |
80 |
140 |
11 |
M10 |
8.7 |
25 |
3.09 |
| KBA50L |
50 |
52 |
61 |
122 |
215 |
102 |
80 |
25 |
100 |
160 |
11 |
M10 |
8.7 |
25 |
6.53 |
| KBA60L |
60 |
58 |
66 |
132 |
240 |
114 |
94 |
30 |
108 |
180 |
12 |
M12 |
10.7 |
25 |
9.29 |
|
