| MODEL
NO. |
SHAFT
DIAMETER |
MAIN
DIMENSIONS |
MOUNTING
DIMENSIONS |
BASIC LOAD
RATING |
WEIGHT(kg) |
| B |
C |
S |
l |
c(kgf) |
Co(kgf) |
| h |
E |
W |
L |
F |
T |
h1 |
θ |
| SME10 |
10 |
15 |
18 |
36 |
32 |
24 |
7 |
6 |
80° |
25 |
20 |
M5 |
10 |
38 |
56 |
0.065 |
| SME12 |
12 |
17 |
20 |
40 |
39 |
27.6 |
8 |
8.5 |
80° |
28 |
26 |
M5 |
10 |
42 |
61 |
0.100 |
| SME13 |
13 |
17 |
20 |
40 |
39 |
27.6 |
8 |
8.5 |
80° |
28 |
26 |
M5 |
10 |
52 |
80 |
0.100 |
| SME16 |
16 |
20 |
22.5 |
45 |
45 |
33 |
9 |
10 |
80° |
32 |
30 |
M5 |
12 |
59 |
91 |
0.150 |
| SME20 |
20 |
23 |
24 |
48 |
50 |
39 |
11 |
10 |
60° |
35 |
35 |
M6 |
12 |
88 |
140 |
0.200 |
| SME25 |
25 |
27 |
30 |
60 |
65 |
47 |
14 |
11.5 |
50° |
40 |
40 |
M6 |
12 |
100 |
160 |
0.45 |
| SME30 |
30 |
33 |
35 |
70 |
70 |
56 |
15 |
14 |
50° |
50 |
50 |
M8 |
18 |
160 |
280 |
0.63 |
| SME35 |
35 |
37 |
40 |
80 |
80 |
63 |
18 |
16 |
50° |
55 |
55 |
M8 |
18 |
170 |
320 |
0.92 |
| SME40 |
40 |
42 |
45 |
90 |
90 |
72 |
20 |
19 |
50° |
65 |
65 |
M10 |
20 |
220 |
410 |
1.33 |
| SME50 |
50 |
53 |
60 |
120 |
110 |
92 |
25 |
23 |
50° |
94 |
80 |
M10 |
20 |
390 |
810 |
3.00 |
|
