| MODEL
NO. |
SHAFT
DIAMETER |
MAIN
DIMENSIONS |
MOUNTING
DIMENSIONS |
WEIGHT(kg) |
| B |
C |
S1 |
| H |
E |
W |
L |
F |
T |
G |
K |
| SWA8L |
12.7 |
17.45 |
25.4 |
50.8 |
88.9 |
28.58 |
6.35 |
34.93 |
6.342 |
63.5 |
42.88 |
3.94 |
0.18 |
| SWA10L |
15.875 |
22.22 |
31.75 |
63.5 |
101.6 |
36.5 |
7.14 |
44.45 |
7.94 |
76.2 |
53.98 |
4.7 |
0.24 |
| SWA12L |
19.05 |
23.8 |
34.92 |
69.85 |
114.3 |
39.67 |
7.92 |
47.63 |
7.925 |
88.9 |
60.325 |
4.7 |
0.41 |
| SWA16L |
25.4 |
30.15 |
41.28 |
82.55 |
152.4 |
49.2 |
9.53 |
60.33 |
10.3 |
114.3 |
73.03 |
5.5 |
0.84 |
| SWA20L |
31.75 |
38.1 |
50.8 |
101.6 |
190.5 |
63.5 |
11.1 |
76.2 |
12.705 |
139.7 |
88.9 |
5.5 |
1.66 |
| SWA24L |
38.1 |
44.45 |
60.32 |
120.65 |
228.6 |
74.6 |
12.7 |
88.9 |
14.29 |
165.1 |
104.78 |
7.1 |
2.60 |
|
