| MODEL
NO. |
SHAFT
DIAMETER |
MAIN
DIMENSIONS |
MOUNTING
DIMENSIONS |
WEIGHT(kg) |
| B |
C |
S1 |
| H |
E |
W |
L |
F |
T |
G |
K |
| SWB8 |
12.7 |
17.45 |
25.4 |
50.8 |
42.88 |
31.8 |
6.528 |
28.7 |
6.342 |
25.4 |
42.88 |
3.94 |
0.058 |
| SWB12 |
19.05 |
23.8 |
34.92 |
69.85 |
52.4 |
44.42 |
7.93 |
41.25 |
7.925 |
31.75 |
60.325 |
4.75 |
0.136 |
| SWB16 |
25.4 |
30.15 |
41.28 |
82.55 |
71.45 |
55.55 |
9.53 |
50.8 |
10.3 |
44.45 |
73.03 |
5.56 |
0.264 |
| SWB20 |
31.75 |
38.1 |
50.8 |
101.6 |
92.08 |
72.21 |
11.88 |
66.65 |
12.705 |
50.8 |
88.9 |
5.56 |
0.585 |
| SWB24 |
38.1 |
44.45 |
60.32 |
120.65 |
101.6 |
82.56 |
12.73 |
76.2 |
14.29 |
63.5 |
104.78 |
7.16 |
0.765 |
| SWB32 |
50.8 |
53.97 |
76.2 |
152.4 |
127 |
103.18 |
15.87 |
98.4 |
15.88 |
82.55 |
133.35 |
10.34 |
1.578 |
|
