| MODEL
NO. |
NUMBER OF BALL |
MAIN
DIMENSIONS |
ECCEN-TRICITY |
BASIC LOAD
RATING |
| INSCRIBED CIRCLE |
OUTER DIAMETER |
LENGTH |
OUT LOCKING GROOVE |
W |
c(kgf) |
Co(kgf) |
| dr |
TOLE-RANCE |
D |
TOLE-RANCE |
L |
TOLE-RANCE |
B |
TOLE-RANCE |
D1 |
| KB8L |
4 |
8 |
+0.009
-0.001 |
16 |
0
-0.009 |
46 |
0
-0.30 |
33 |
0
-0.30 |
15.2 |
1.1 |
0.015 |
43 |
82 |
| KB10L |
4 |
10 |
19 |
0
-0.011 |
55 |
44 |
18 |
1.3 |
60 |
112 |
| KB12L |
4 |
12 |
22 |
61 |
45.8 |
21 |
1.3 |
83 |
160 |
| KB16L |
5 |
16 |
+0.011
-0.001 |
26 |
68 |
49.8 |
24.9 |
1.3 |
94 |
182 |
| KB20L |
5 |
20 |
32 |
0
-0.013 |
80 |
61 |
30.5 |
1.6 |
0.017 |
140 |
280 |
| KB25L |
6 |
25 |
+0.013
-0.002 |
40 |
112 |
0
-0.40 |
82 |
0
-0.40 |
38 |
1.85 |
160 |
320 |
| KB30L |
6 |
30 |
47 |
123 |
104.2 |
44.5 |
1.85 |
255 |
560 |
| KB40L |
6 |
40 |
+0.016
-0.004 |
62 |
0
-0.015 |
151 |
121.2 |
59 |
2.15 |
0.020 |
350 |
820 |
| KB50L |
6 |
50 |
75 |
192 |
155.2 |
72 |
2.65 |
620 |
1622 |
| KB60L |
6 |
60 |
90 |
0
-0.020 |
209 |
170 |
86.5 |
3.15 |
0.025 |
770 |
2040 |
|
