| MODEL
NO. |
SHAFT
DIAMETER |
MAIN
DIMENSIONS |
MOUNTING
DIMENSIONS |
WEIGHT(kg) |
| B |
C |
S1 |
| H |
E |
W |
L |
F |
θ |
T |
h1 |
K |
| SWB8L-OP |
12.7 |
17.45 |
25.4 |
53 |
88.9 |
28.7 |
60° |
6.53 |
10.64 |
6.342 |
63.5 |
42.88 |
3.94 |
0.123 |
| SWB12L-OP |
19.05 |
23.8 |
34.92 |
69.85 |
114.3 |
39.7 |
60° |
7.87 |
15.87 |
7.925 |
88.9 |
60.325 |
4.75 |
0.305 |
| SWB16L-OP |
25.4 |
30.15 |
41.28 |
82.55 |
152.4 |
50.8 |
60° |
9.53 |
19.3 |
10.3 |
114.3 |
73.03 |
5.56 |
0.612 |
| SWB20L-OP |
31.75 |
38.1 |
50.8 |
101.6 |
190.5 |
63.5 |
60° |
11.88 |
24.2 |
12.705 |
139.7 |
88.9 |
5.56 |
1.128 |
| SWB24L-OP |
38.1 |
44.45 |
60.32 |
120.65 |
228.6 |
74.6 |
60° |
12.7 |
29.5 |
14.29 |
165.1 |
104.78 |
7.16 |
1.778 |
|
