| MODEL
NO. |
SHAFT
DIAMETER |
MAIN
DIMENSIONS |
WEIGHT(kg) |
| h |
E |
W |
L |
F |
G |
P |
B |
S |
| SKW4 |
0.25˝
6.35 |
0.6875˝
17.463 |
0.75˝
19.05 |
1.50˝
38.10 |
0.50˝
12.70 |
1.063˝
27 |
0.25˝
6.35 |
0.50˝
12.7 |
1.125˝
28.575 |
0.156˝
4.0 |
0.015 |
| SKW6 |
0.375˝
9.525 |
0.75˝
19.05 |
0.8125˝
20.637 |
1.625˝
41.28 |
0.563˝
14.3 |
1.187˝
30.16 |
0.25˝
6.35 |
0.688˝
17.46 |
1.25˝
31.75 |
0.156˝
4.0 |
0.021 |
| SKW8 |
0.50˝
12.70 |
1.0˝
25.40 |
1.0˝
25.40 |
2.00˝
50.80 |
0.63˝
16 |
1.63˝
41.4 |
0.25˝
6.35 |
0.88˝
22.35 |
1.50˝
38.10 |
0.188˝
4.8 |
0.035 |
| SKW10 |
0.625˝
15.875 |
1.0˝
25.40 |
1.25˝
31.75 |
2.5˝
63.5 |
0.688˝
17.46 |
1.75˝
44.45 |
0.31˝
7.88 |
1.0˝
25.40 |
1.875˝
47.625 |
0.218˝
5.6 |
0.052 |
| SKW12 |
0.75˝
19.05 |
1.25˝
31.75 |
1.25˝
31.75 |
2.5˝
63.5 |
0.75˝
19.05 |
2.13˝
54.1 |
0.31˝
7.88 |
1.25˝
31.75 |
2.00˝
50.80 |
0.218˝
5.6 |
0.082 |
| SKW16 |
1.0˝
25.40 |
1.50˝
38.10 |
1.5315˝
38.9 |
3.063˝
77.8 |
1.0˝
25.40 |
2.56˝
65 |
0.38˝
9.68 |
1.50˝
38.10 |
2.5˝
63.5 |
0.281˝
7.2 |
0.145 |
| SKW20 |
1.25˝
31.75 |
1.75˝
44.45 |
1.875˝
47.625 |
3.75˝
95.25 |
1.13˝
28.7 |
3˝
76.2 |
0.44˝
11.18 |
2.00˝
50.80 |
3˝
76.2 |
0.346˝
8.8 |
0.254 |
| SKW24 |
1.50˝
38.10 |
2.00˝
50.80 |
2.1875˝
55.563 |
4.375˝
111.125 |
1.25˝
31.75 |
3.5˝
88.9 |
0.50˝
12.70 |
2.25˝
57.15 |
3.5˝
88.9 |
0.346˝
8.8 |
0.362 |
| SKW32 |
2.00˝
50.80 |
2.5˝
63.5 |
2.75˝
69.85 |
5.5˝
139.7 |
1.50˝
38.10 |
4.5˝
114.3 |
0.63˝
16 |
3˝
76.2 |
4.5˝
114.3 |
0.406˝
10.5 |
0.716 |
|
