| MODEL NO. |
NUMBER OF
BALL ROWS |
MAIN
DIMENSIONS |
ECCEN-TRICITY
(MAX.) |
BASIC LOAD
RATING |
| INSCRIBED CIRCLE |
OUTER DIAMETER |
LENGTH |
OUT LOCKING GROOVE |
W |
c(kgf) |
Co(kgf) |
| dr |
TOLE-RANCE |
D |
TOLE-RANCE |
L |
TOLE-RANCE |
B |
TOLE-RANCE |
D1 |
| LM3 |
4 |
3 |
0-0.008 |
7 |
0-0.009 |
10 |
0-0.12 |
|
|
|
|
0.008 |
7 |
11 |
| LM4 |
4 |
4 |
8 |
12 |
|
|
|
|
9 |
13 |
| LM5 |
4 |
5 |
10 |
15 |
10.2 |
0-0.20 |
9.6 |
1.1 |
17 |
21 |
| LM6 |
4 |
6 |
0-0.009 |
12 |
0-0.011 |
19 |
0-0.20 |
13.5 |
11.5 |
1.1 |
0.012 |
21 |
27 |
| LM8S |
4 |
8 |
15 |
17 |
11.5 |
14.3 |
1.1 |
18 |
23 |
| LM8 |
4 |
8 |
15 |
24 |
17.5 |
14.3 |
1.1 |
27 |
41 |
| LM10 |
4 |
10 |
19 |
0-0.013 |
29 |
22 |
18 |
1.3 |
38 |
56 |
| LM12 |
4 |
12 |
21 |
30 |
23 |
20 |
1.3 |
42 |
61 |
| LM13 |
4 |
13 |
23 |
32 |
23 |
22 |
1.3 |
52 |
79 |
| LM16 |
5 |
16 |
28 |
37 |
26.5 |
27 |
1.6 |
79 |
120 |
| LM20 |
5 |
20 |
0-0.010 |
32 |
0-0.016 |
42 |
30.5 |
30.5 |
1.6 |
0.015 |
88 |
140 |
| LM25 |
6 |
25 |
40 |
59 |
0-0.30 |
41 |
0-0.30 |
41 |
1.85 |
100 |
160 |
| LM30 |
6 |
30 |
45 |
64 |
44.5 |
44.5 |
1.85 |
160 |
220 |
| LM35 |
6 |
35 |
0-0.012 |
52 |
0-0.019 |
70 |
49.5 |
49.5 |
2.1 |
0.020 |
170 |
320 |
| LM40 |
6 |
40 |
60 |
80 |
60.5 |
60.5 |
2.1 |
220 |
410 |
| LM50 |
6 |
50 |
80 |
100 |
74 |
74 |
2.6 |
390 |
810 |
| LM60 |
6 |
60 |
0-0.015 |
90 |
0-0.022 |
110 |
85 |
85 |
3.15 |
0.025 |
480 |
1020 |
|
