| MODEL
NO. |
NUMBER OF BALL |
MAIN
DIMENSIONS |
ECCEN-TRICITY |
BASIC LOAD
RATING |
| INSCRIBED CIRCLE |
OUTER DIAMETER |
LENGTH |
OUT LOCKING GROOVE |
W |
hl |
θ |
c(kgf) |
Co(kgf) |
| dr |
TOLE-RANCE |
D |
TOLE-RANCE |
L |
TOLE-RANCE |
B |
TOLE-RANCE |
D1 |
| LM10OP |
3 |
10 |
0
-0.009 |
19 |
0
-0.013 |
29 |
0
-0.20 |
22 |
0
-0.20 |
18 |
1.3 |
6.8 |
80° |
0.012 |
38 |
56 |
| LM12OP |
3 |
12 |
21 |
30 |
23 |
a20 |
1.3 |
8 |
80° |
42 |
61 |
| LM13OP |
3 |
13 |
23 |
32 |
23 |
22 |
1.3 |
9 |
80° |
52 |
79 |
| LM16OP |
4 |
16 |
28 |
37 |
26.5 |
27 |
1.6 |
11 |
80° |
79 |
120 |
| LM20OP |
4 |
20 |
0
-0.010 |
32 |
0
-0.016 |
42 |
30.5 |
30.5 |
1.6 |
11 |
60° |
0.015 |
88 |
140 |
| LM25OP |
5 |
25 |
40 |
59 |
0
-0.30 |
41 |
0
-0.30 |
38 |
1.85 |
12.5 |
60° |
100 |
160 |
| LM30OP |
5 |
30 |
45 |
64 |
44.5 |
43 |
1.85 |
15 |
60° |
160 |
280 |
| LM35OP |
5 |
35 |
0
-0.012 |
52 |
0
-0.019 |
70 |
49.5 |
49 |
2.1 |
17.5 |
60° |
0.020 |
170 |
320 |
| LM40OP |
5 |
40 |
60 |
80 |
60.5 |
57 |
2.1 |
20 |
60° |
220 |
410 |
| LM50OP |
5 |
50 |
80 |
100 |
74 |
76.5 |
2.6 |
25 |
60° |
390 |
810 |
| LM60OP |
5 |
60 |
0
-0.015 |
90 |
0
-0.022 |
110 |
85 |
86.5 |
3.15 |
30 |
60° |
0.025 |
480 |
1020 |
|
